WG3100-Series GSM VoIP Gateway User Manual
_______________________________________________________________________________
Techroutes Network Pvt. Ltd.
29
Table 4-5-1 Local network
Obtain IP Address
Automatically
Enable the device obtain IP Address automatically or not. Default is enabling
Use the Following IP
Address
Configure the "IP Address", "Subnet Mask" and "Default Gateway" by manual
Need ISP offer the account and password, Use this mode when there is not router in the local network
Message transmit unit, default is 1400
Obtain DNS Server
Address Automatically
When enable the WAN port option of "Obtain DNS Server Address Automatically”, which will be
enabled subsequently.
Use the Following DNS
Server Addresses
Fill in the IP address of "Primary DNS Server" and "Secondary DNS Server"
4.5.2 ARP
The ARP function mainly used to query and add the map of IP and MAC. There are static or dynamic ARP entries.
