WG3100-Series GSM VoIP Gateway User Manual
_______________________________________________________________________________
Techroutes Network Pvt. Ltd.
39
Operator configuration aim to set operator code for batch of SIMs. Inserted SIM cards will match with IMSI prefix and register SIM
card to the code as per setting.
4.7.8 BCCH
BCCH (Broadcast Control Channel): BCCH is a logical broadcast channel used by the base station in a GSM/WCDMA network to
send information about the identity of the network. The information is used by a mobile station to get access to the network.
Information includes the Mobile Network Code (MNC), the Location Area Code (LAC) and a list of frequencies used by the
neighboring cells.
Configuration Procedures for BCCH:
Step 1. In the navigation tree on the left, click Mobile Configuration BCCH.
Step 2. Drag the scroll bar on the bottom of the interface, and you will see buttons.
Click the button of a specific port, and you will see the following interface
Step 3. Click the drag-down box on the right of BCCH Mode, and select a mode.
Default: All frequencies will be automatically matched with the gateway.
