The Challenger Version 8.0 User Guide : Issue I , Revision I : October 1997
TEST REPORT - Menu Option 6
ACCESS TEST REPORT: This function is used to determine the results of the Access Test which is done on specific
inputs and cameras to see if they were operating correctly. The inputs are those that have been programmed to be included
in testing and which operate when a building is occupied. All the cameras are tested.
Inputs:
The untested inputs will be listed either:
One at a time eg. Untested Access On 25. Reception Hold Up
NEXT or ENTER
or
As a list of numbers eg. Untested Access On 25, 26, 27.
Input No:
From either display:
NEXT ~ Update the list of inputs and display the remaining inputs in the list (if any).
or ENTER ~ Display camera test results if applicable, otherwise return to the menu.
or ? ENTER ~ Display the full input name.
Note: Where an input is displayed as untested, it could mean that it has not been tested
because it was missed, or, because it was faulty and could not be tested.
Cameras:
The results of camera tests will be displayed provided that:
i) The user conducting the access test has been programmed to test cameras.
ii) The User has Area 1 assigned in their Alarm Group and is testing Area 1.
All cameras tested successfully:
The display will show:
All Cameras Have Tested Successfully
Press ENTER
ENTER ~ Return to the menu.
Untested cameras will be listed:
eg. Cameras Not Tested : 1, 2.
Press ENTER
ENTER ~ Return to menu.
See Also: Access Test
