38 V8-U-TXT.PM6 : Issue I , Revision I : October 1997
FILM COUNTERS - Menu Option 8
This function is used to display the current frame number position on each of the security camera films.
If you maintain a log on frame counts it will indicate whether the cameras have operated since they were last checked.
eg. Film Counts 1: 0123 2:1077 3:0056 4:----
Press ENTER
ENTER ~ Move on to the film count display for cameras 5 to 8.
The display will show:
Film Counts 5: ---- 6:---- 7:---- 8:----
Press ENTER
ENTER ~ Return to the menu.
Note: 1. If a camera is fitted with a film out detector and that camera does not have a film in it, the frame count will
be displayed as OUT.
OUT will be removed when film is loaded.
2. A possible 8 cameras may be displayed.
Any of the 8 camera positions which does not have a camera fitted will display the frame count as ‘----’.
3. A frame count may be from 0 to 9999.
