Field or control Description
Data Sets the data pattern for which to search.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Mark When = Data or Label & Data.
Data Low Sets the low value of the data pattern range for which to search.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Mark When = Data and Mark When Data = Inside Range or Outside Range.
Data High Sets the high value of the data pattern range for which to search.
Tap the Binary, Hex, or Octal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Mark When = Data and Mark When Data = Inside Range or Outside Range.
SSM Sets the Sign/Status Matrix (SSM) bit condition for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark When = Data or Label & Data.
SDI Sets the Source/Destination Identifier (SDI) bit condition for which to search.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Mark When = Data or Label & Data.
Error Type Sets the error condition for which to search.
Available when Mark When = Error.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Menus and dialog boxes
232 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
