Eye Diagram plot configuration menu
Use this menu to change settings of a displayed Eye Diagram plot.
To open the Eye Diagram plot menu, double-tap anywhere in the Eye Diagram plot view.
Settings panel (Eye Diagram plot configuration menu) fields and controls.
Field or control Description
AutoScale Toggles AutoScale on or off. Turn AutoScale off to manually set the X and Y-axis range to view
an area of interest.
When AutoScale is off, a small Zoom window appears in the plot. Drag the blue vertical bar in
the Zoom window to view that area in the main Plot view. Use the Zoom and Pan front-panel
knobs to change the zoom area and position.
X-Axis From, To Sets the beginning and end scale range to display in the plot for the X-Axis scales.
Only available when AutoScale is off (unchecked).
Y-Axis From, To Sets the beginning and end scale range to display in the plot for the Y-Axis scales.
Only available when AutoScale is off (unchecked).
Gridlines Selects which gridlines to show in the plot. Select the grid style that meets your measurement
needs.
Save panel fields and controls.
Use the Save panel controls to save the plot image or date to a file, for inclusion in reports or further analysis in other
applications.
Field or control Description
Save Plot Image Tap to open the Save As menu. Navigate to the location where you want to save the plot image.
Enter a file name in the File Name field. Select the image file format (PNG, BMP, or JPG).
Tap OK to save the plot image.
Save Plot Data Tap to open the Save As menu. Navigate to the location where you want to save the plot data.
Enter a file name in the File Name field.
Tap OK to save the plot data as a comma-separated values (.csv) file.
Closing a plot view.
To close (delete) a Plot view, tap the X in the upper right corner of the view.
Deleting the Measurement badge that enabled the plot also closes the plot.
Menus and dialog boxes
318 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
