Edge Search configuration menu
Use the Edge search to mark when the specified edge condition occurs on an analog, digital, math, or reference waveform.
To create a new edge search:
1. Tap Add New... Search.
2. Set the Search Type to Edge.
3. Select the search Source.
4. Use the menu fields to set the search parameters.
To change the settings on an existing search, double-tap the search badge and make necessary changes.
Edge Search configuration menu fields and controls.
Field or control Description
Display Sets the display of the mark icons on or off. If you have multiple searches defined, the control
turns off just the marks for the selected search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Search Type Set to Edge.
Source Lists the source channel or waveform to use to trigger or search. Types that require multiple
inputs will replace this control with a different source definition control.
Level Sets the amplitude level that the signal must pass through to be considered a valid transition.
Set to 50% Sets the threshold at 50% of the measured signal transition range. 50% is calculated as (Top +
Bottom)/2.
Slope Sets the signal transition direction to detect. (rising, falling, or either direction).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Other search types.
Bus Search configuration menus on page 230
Logic search configuration menu on page 251
Pulse Width Search configuration menu on page 253
Rise/Fall Time Search configuration menu on page 255
Runt Search configuration menu on page 257
Setup and Hold Search configuration menu on page 258
Timeout Search configuration menu on page 260
Window Search configuration menu on page 262
Menus and dialog boxes
250 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
