Self Test configuration menu (Utility menu)
Use this menu to view power-on diagnostic results, run extended self tests, and verify the 250 kΩ termination control works on
input channels.
To open the Self Test configuration menu:
1. Tap Utility in the Menu bar.
2. Tap Self Test....
Tap anywhere outside of the menu to close the menu.
NOTE. Remove all input signals before running the extended self tests.
Self Test configuration menu fields and controls.
Field or control Description
250 kΩ Verification Opens a menu to verify that 250 kΩ termination can be enabled or disabled for every channel.
Closing the menu restores the normal termination setting of all connected probes.
Export Log Files Opens a menu that lets you save instrument log files to a .zip-compressed file. The log file is a
valuable information resource when working with Tektronix Customer Support to troubleshoot a
problem or report an issue.
NOTE. The Export Log Files button and function is not available on instruments with option 5-
SEC (Enhanced Security) installed.
Power-on Self test Results Displays the power-on self test status (Passed or Failed).
Extended Self Test Results Lists the status of each Extended self tests (Passed or Failed).
If one or more tests fail at power-on, tap on Run Self Test and see if the test or tests continue
to fail. If tests continue to fail, contact your nearest Tektronix Service Center for help with
resolving the problem.
Run N Times Sets the number of times to run the extended self tests.
Run Self Test / Abort Self
Test
Tap Run Self Test to run the extended self tests. While tests are running, the button changes
to Abort Self Test. When self tests are stopped, the button reverts to Run Self Test.
NOTE. Remove all input signals before running the extended self tests.
Tap the Abort Self Test button anytime to stop testing.
