Field or control Description
CRC Type Sets the CRC error type for which to search.
Available when Mark On = Error and Error Type = CRC.
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
SPI serial bus search configuration menu
Use the SPI Search configuration menu to define conditions to search for and mark on an SPI bus waveform. You can have
multiple searches on the same bus.
NOTE. Requires option SREMBD.
Field or control Description
Display Enables or disables displaying search marks on this search.
Stop Acquisition if Event
Found
Stops input acquisition when the search event occurs. Default is not enabled.
Source Select the SPI bus that you want to search.
Mark On Select the type of information for which to search.
Data Words Sets the number of data words (1 word = 8 bits) for which to search (one to sixteen words). Use
the A knob to change the value.
Only available when Mark On = Data.
Data Sets the data pattern for which to search. The number of bits shown depends on the Data
Words setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Only available when Mark On = Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s).
Copy Trigger Settings to
Search
Sets the search criteria to match the current oscilloscope trigger settings.
Copy Search Settings to
Trigger
Sets the current oscilloscope trigger settings to match the search criteria.
Menus and dialog boxes
246 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
