Socket Server panel fields or controls. Use the following socket server settings to set up and use a socket server between
your oscilloscope and a remote terminal or computer.
Field or control Description
Socket Server Tap to toggle the socket server On or Off.
Protocol Tap to select a protocol, either None or Terminal.
A communication session run by a user at a keyboard typically uses a terminal protocol. An
automated session might handle its own communications without such protocol from the
oscilloscope.
Port Enter the port number using the multipurpose knob or virtual keypad.
AUX Out panel fields and controls. Use the following settings to select the signal that is output on the rear-panel AUX Out
signal connector.
Field or control Description
AUX Out Signal Tap to select the signal type to send to the AUX Out connector.
Trigger sends a pulse for each trigger occurrence.
Reference Clock outputs the instrument's reference signal, whether generated internally or
supplied from the REF In connector.
AFG Sync sends a pulse that is synchronized to the AFG output signal.
Polarity Tap to select the polarity of the trigger signal (positive or negative pulse per trigger event). The
polarity control is only present for the Trigger output.
