Field or control Description
Vertical Center Sets the area vertical center, in amplitude units, as the point halfway between the topmost
vertex and bottommost vertex.
Flip Vertical Flips the area vertically around its Vertical Center value.
Width Sets the area width, in time units, between the leftmost vertex and the rightmost vertex.
Horizontal Center Sets the area horizontal center, as time units, as the point halfway between the leftmost vertex
and rightmost vertex.
Flip Horizontal Flips the area horizontally around its Horizontal Center value.
Rotate Rotates the area in units of degrees, from 0° to 360°.
The rotation is an absolute angle measurement referenced from 0°, where 0° is the position of
the area when it was first created. For example, if you rotate the area 40°, and then rotate it
again with 20°, the resulting area rotation is 20°.
The area height and width are relative to the current area orientation, and automatically change
places as needed when the area is rotated.
Edit Vertices panel fields and controls
Field or control Description
Define Area A table that lists the X (time) and Y (amplitude) values for each vertex (point) of the area. Use
the scroll bar to show points if there are more than nine points in the area.
Selecting a row in the table highlights the associated vertex on the area.
Use the Multipurpose knobs to change the value of the X or Y settings, or double-tap a setting
and enter the value directly.
Insert Point Inserts a new row above the selected row and creates a new vertex on the area shape. The
new vertex is halfway between the vertices defined in the prior row and the following row in the
table.
Delete Point Deletes the currently selected point, keeps the row selected, and moves all rows below it up
one row.
The Delete Point button is not available when a triangular area is selected.
Reset Points Deletes all but three data points from the table. The remaining three data points are set to a
default triangle, set to two divisions for height and width, and centered in the waveform area.
NOTE. Redo and Undo are available for most Edit Vertices panel controls.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 407
