Saving files with the front-panel User button. Pushing the front-panel User button automatically saves the file type last
selected in the Save As configuration menu. If no saves have been performed since the instrument power-up, pushing the User
button opens the Save As configuration menu. Select the type of save operation you want to perform and tap OK. After that,
pushing the User button automatically saves the file type.
NOTE. The User button is not assigned a specific save type by default; it retains whatever save action was last selected in the
Save As configuration menu.
File operations and Microsoft Windows 10 Operating System SSD. Instruments with Windows 10 SSD will display the
standard Windows file tools to navigate to and select files and folders.
The Windows operating system assigns the first available drive letter (typically E:) to the first USB device attached to the
oscilloscope, regardless of which port the USB device is plugged into. The next plugged-in USB device is assigned the next
available drive letter (such as F:) and so on for other installed devices. This is different from standard instruments (without
Windows 10 installed), which assign a non-changing drive letter to each USB port.
Menus and dialog boxes
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 281
