LIN serial bus trigger settings panel
NOTE. Requires option SRAUTO.
Field or control Description
Source Select the LIN bus on which to trigger.
Trigger On Select the type of information on which to trigger.
Identifier Sets the identifier pattern on which to trigger.
Tap the Binary, Hex, or Decimal field and use the A and B knobs to select and change the
values. Or double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Identifier or Identifier & Data.
Data Sets the data pattern on which to trigger. The number of bits shown depends on the Data Bytes
setting.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Data or Identifier & Data.
Trigger When Sets the trigger when condition.
When set to Inside Range or Outside Range, fields are displayed to set a high and low
boundary pattern for the specified trigger type.
Available when Trigger On = Data or Identifier & Data.
Data Bytes Sets the number of data bytes on which to trigger (one to eight bytes). Use the A knob to
change the value.
Available when Trigger On = Data or Identifier & Data.
A, B knob controls Use the A knob to select (highlight) the digit(s) to change.
Use the B knob to change the value of the digit(s). Or double-tap on the field and use the virtual
keypad to enter values.
Error Type Sets the LIN error type on which to trigger.
Available when Trigger On = Error.
Menus and dialog boxes
358 MSO54, MSO56, MSO58, MSO58LP, MSO64 Help
