Power is supplied to the power supply and some other boards whenever the AC power cord is connected to a live mains
circuit, putting the instrument in standby mode.
3. Push the front panel power button to power the instrument on and off.
The power button color indicates instrument power states:
Unlit – no AC power applied
Yellow – standby mode
Blue – powered on
4. To completely remove power from the instrument, disconnect the power cord.
5. To transport the instrument with its power cord, flip out the power cord supports on the upper edge of the rear panel and
wrap the power cord around the supports.
Check that oscilloscope passes power-on self tests
Power-on self tests verify that all oscilloscope modules are working correctly after power up.
Prerequisite: For the MSO58LP, connect a monitor to a video output on the rear panel and connect a mouse to a USB port.
1. Power on the oscilloscope and wait until the oscilloscope screen appears.
2. Select Utility > Self Test from the top-edge Menu bar to open the Self Test configuration menu.
3. Check that the status of all power-on self tests are Passed.
If one or more power-on self tests shows Failed:
a. Power cycle the oscilloscope.
b. Tap Utility > Self Test. If one or more power-on self tests still shows Failed, contact Tektronix Customer Support.
Installing and activating Windows 10 option
Use the following instructions to install the Microsoft Windows 10 solid state drive (upgrade installed after purchasing the
instrument) and activate Windows 10 on the instrument.
NOTE. The Windows option cannot be installed in a Low Profile instrument.
Install the Windows SSD drive
The optional SSD assembly installs in the bottom of the instrument.
Prerequisite: Wear an anti-static wrist strap connected to the instrument chassis while installing this drive.
1. Remove all cables from the front and rear of the instrument, including the power cable.
2. Position the instrument on its back, with the bottom facing you.
Install your instrument
MSO54, MSO56, MSO58, MSO58LP, MSO64 Help 27
