Field or control Description
Data Sets the condition and value of the slow channel data on which to trigger.
Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤). The default is
=.
Tap the Binary or Hex field and use the A and B knobs to select and change the values. Or
double-tap on the field and use the virtual keypad to enter values.
Available when Trigger On = Slow Channel.
Trigger When Sets the trigger when condition.
Tap the down arrow and select the condition on which to trigger (=, ≠, >, <, ≥, ≤, Inside Range,
Outside Range). The default is =.
When set to Inside Range or Outside Range, fields are displayed to set high and low
boundary values for the number of clock ticks on which to trigger.
Available when Trigger On = Pause Pulse.
Number of Ticks Sets the number of Pause Pulse ticks on which to trigger.
Tap the Ticks High or Tick Low field and use the A and B knobs to set the values.
Available when Trigger On = Pause Pulse and Trigger When is set to =, ≠, >, <, ≥, or ≤.
Ticks High, Ticks Low) Sets the highest and lowest range of the number of Pause Pulse ticks on which to trigger.
Tap the Ticks High or Tick Low field and use the A and B knobs to set the values.
Available when Trigger On = Pause Pulse and Trigger When = Inside Range or Outside
Range.
Error Type Sets the error type on which to trigger. Tap the arrow and select the error condition.
Available when Trigger On = Error.
CRC Type Sets the CRC error type on which to trigger (Fast Channel or Slow Channel).
Available when Trigger On = Error and Error Type = CRC.
