Operating Basics
Active menu or option Knob function Description
Vertical ► Pro
be ►
Vo ltage ► Attenuation
Value entry
For a channel menu (such as the CH
1 menu), sets the attenuation factor in
the oscillosc
ope
Vertical ► Probe ►
Current ► Sca
le
Value entry
For a of chann
el menu (such as the
CH 1 menu), sets the scale in the
oscilloscope
AutoRange. Displays the Autorange Menu, and activates or deactivates the
autoranging function. When autoranging is active, the adjacent LED lights.
Save/Recall. Displays the Save/Recall Menu for setups and waveforms.
Measure. Displays the a utomated measurements menu.
Acquire. Displays the Acquire Menu.
Ref. Displays the Reference Menu to quickly display and hide reference
wavefo
rms stored in the oscilloscope non-volatile memory.
Utility. Displays the Utility Menu.
Cursor. Displays the Cursor Menu. Cursors remain visible (unless the Type
option is set to Off) after you leave the Cursor Menu but are not adjustable.
Display. Displays the Display Menu.
Help. Displays the Help Menu.
Default Setup. Recalls the factory setup.
AutoSet. Automatically sets the oscilloscope controls to produce a usable display
of the input signals.
Single. (Single sequence) Acquires a single waveform and then stops.
Run/Stop. Continuously acquires waveforms or stops the acquisition.
Starts the print operation to a PictBridge compatible printer, or performs the
Save function to the USB flash drive.
Save. An LED indicates when the print button is configuredtosavedatatothe
USB flash drive.
TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual 17
