USB Flash Drive and Device Ports
Save Image, Save Setup,
and Save Wa veform
Options
You can save a sc
reen image, the oscilloscope settings, or waveform data to a file
on the USB flash drive through the Save/Recall menu.
Each save opti
on operates in a similar w ay. As an example, to save a screen image
file to a flash drive, follow these steps:
1. Insert a USB
flash d rive into the USB Flash Drive port.
2. Push Utility ► Options ► Printer Setup and set the following options:
Ink Saver On, Off
Prints the screen image on a white
background when you select On
Layout Portrait, Landscape Printer output orientation
3. Access the screen you want to save.
4. Push the Save/Recall front panel button.
5. Select t
he Action ► Save Image ► Save option.
The oscilloscope saves the screen image in the current folder and
automa
tically generates the filename.(Seepage91,Save/Recall.)
Recall Setup, and Recall
Waveform Options
You can recall the oscilloscope settings or waveform data from a file on the USB
flash drive through the Save/Recall menu.
Each recall option operates in a similar way. As an example, to recall a waveform
file from a USB flash drive, follow these steps:
1. Insert the USB flash drive that contains the desired waveform file into the
USB Flash Drive port o n the front of the oscilloscope.
2. Push the Save/Recall front panel button.
3. Select the Action ► Recall Waveform ► Select File option.
You can use the Change Folder option to navigate to another folder on the
flash drive.
4. Turn the multipurpose knob to select the waveform file to recall.
T
he name of the file in the Recall option changes as you scroll.
66 TDS2000C and TDS1000C-EDU Series Oscilloscope User Manual
