Tektronix TPS2000 Series User Manual

TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
4-1
Performance Verification
This chapter contains performance verification procedures for the specifications
marked with the n symbol. The following equipment, or a suitable equivalent,
is required to complete these procedures.
Equipment Required
Description
Minimum
requirements
Examples
DC Voltage Source 17.5mVto7V,±0.5%
accuracy
Wavetek 9100 Universal
Calibration System with
Os
c
illos
c
o
p
eC
a
libr
a
tion
Leveled Sine Wave Generator 50 kHz and 200 MHz, ±3%
amplitude accuracy
O
s
c
i
l
l
o
s
c
o
p
e
C
a
l
i
b
r
a
t
i
o
n
Module (Option 250)
Fluke 5500A Multi-product
C
l
i
b
t
i
t
h
O
i
l
l
Time Mark Generator 10 ms period, ±10 ppm
accuracy
C
a
libr
a
tor with Os
c
illos
c
ope
Calibration Option (Option
5500A-SC)
50 Ω BNC Cable BNCmaletoBNCmale,
≈ 1 m (36 in) long
Tektronix part number
012-0482-XX
50 Ω BNC Cable BNCmaletoBNCmale,
≈ 25 cm (10 in) long
Tektronix part number
012-0208-XX
50 Ω Feedthrough
Termination
BNC male and female
connectors
Tektronix part number
011-0049-XX
Dual Banana to BNC Adapter Banana plugs to BNC female Tektronix part number
103-0090-00
BNC T Adapter BNC male to dual BNC
female connectors
Tektronix part number
103-0030-00
