Adjustment Procedures
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
5-3
10-inch
BNC cable
10-inch
BNC cables
10-inch
BNC cables
10-inch
BNC cables
Four Channel
Digitizing oscilloscope
Two Channel
Digitizing oscilloscope
BNC ‘T’ connector
DC voltage setup 1
+--
DC voltage source
Dual banana to
BNC adapter
BNC cable
DC voltage setup 2
+--
DC voltage source
Dual banana to
BNC adapter
BNC cable
Sine wave generator setup
Leveled sine
wave generator
Output
50 Ω feedthrough terminator
(Table 5--2 and 5--3 list proper
channel)
BNC cable
BNC ‘T’
connectors
BNC cable
10-inch BNC cable
BNC ‘T’ connector
Square wave
generator
Output
50 Ω feedthrough terminator
(Table 5--2 and 5--3 list proper
channel)
BNC cable
Edge setup
Two Channel
Digitizing oscilloscope
Four Channel
Digitizing oscilloscope
Two Channel
Digitizing oscilloscope
Figure 5- 1: Adjustment setups
