TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
5-1
Adjustment Procedures
This section contains an adjustment procedures for the TPS2000 Series
oscilloscopes.
Only qualified personnel should perform service procedures. Read the Service
Safety Summary and the General Safety Summary at the beginning of this manual
before performing any service procedures.
NOTE. The voltage references inside TPS2000 Series oscilloscopes are very
stable over time and should not require routine updates. Before performing any
procedure in this chapter, first verify that the oscilloscope does not meet
specifications. Refer to the chapter Performance Verification to verify the
specifications.
Required Equipment
The equipment described in Table 5--1, or a suitable equivalent, is required to
complete the procedure.
Table 5- 1: Required equipment
Description Minimum requirements Examples
DC Voltage Source --20Vto20V,±0.1%
accuracy
Wavetek 9100 Universal Cali bration
System with Oscilloscope
Calibration Module (Option 250)
F
l
k
5
5
0
0
A
M
l
t
i
d
t
Leveled Sine Wave
Generator
60 kHz and 200 MHz, ±0.6%
amplitude accuracy
Fluke 5500
A
Multi-produ
c
t
Calibrator with Oscilloscope
Calibration Option
(Option 5500A-SC)
50 Ω BNC Cable BNCmaletoBNCmale,
≈ 1 m (36 in) long
Tektronix part number 012-0482-00
50 Ω BNC Cable (two) BNCmaletoBNCmale,
≈ 25 cm (10 in) long
Tektronix part number 012-0208-00
50 Ω Feedthrough
Termination
BNC male and female
connectors
Tektronix part number 011-0049-01
Dual Banana to BNC
Adapter
Banana plugs to BNC female Tektronix part number 103-0090-00
BNC T One mal e and two female
BNC connectors
Tektronix part number 103-0030-00
