Specifications
TPS2000 Series Digital Storage Oscilloscopes S ervice Manual
1-7
Table 1- 1: Oscilloscope general characteristics (Cont.)
Measurements
Cursors Types Amplit ude difference between cursors (∆V, ∆A, ∆VA)
Time diff erence between cursors (∆t)
Reciprocal of ∆tinHertz(1/∆t)
Automatic Measurements Frequency, Period, Mean, Pk-Pk, Cycle RMS, Min, Max, Rise Time, Fall Time, Pos Width,
Neg Width
Probe Compensator Output
Output Voltage, typical 5V±10% into ≥1MΩ load
Frequency, typical 1 kHz
Adjustment I nterval
The recommended factory calibration interval is one year.
Table 1- 2: Oscilloscope display charact eristics
Type 145 mm (5.7 in) diagonal liquid crystal
Resolution 320 x 240 vertical pixels
Brightness Adjustable
Contrast Adjustable, temperature compensated
Backlight Intensity
1
,typical 60 to 100 cd/m
2
1
Available through the display menu.
Table 1- 3: Oscilloscope physical charact eristics
Size Height 160.8 mm (6.33 in)
Width 336.3 mm (13.24 in)
Depth 129.5 mm (5.10 in)
Weight, approximate Instrument only 2.7kg(6.0lbs)
1 battery installed 3.2kg(7.0lbs)
2 batteries inst alled 3.7kg(8.0lbs)
Table 1- 4: Power source characteristics
Source Voltage of the AC Adapter 90 to 264 VAC
rms
from 45 Hz through 66 Hz
Power Consumption Instrument only: 30 watts max.
AC input to AC adapter: 36 watts.
