Maintenance
TPS2000 Series Digital Storage Oscilloscopes Service Manual
6-- 5
Removal and Installation Procedures
This section describes how to remove and install the major mechanical and
electrical modules of the oscilloscope. It provides the following information:
H Replacement Procedures. Page 6--6 lists the procedures for removal and
installation of major modules.
H Tools Required. Page 6--6 describes the tools needed to perform these
procedures.
Read this section to prepare for module removal and installation.
WARNING. Only qualified personnel should perform service procedures. Before
doing this or any other procedure in this manual, read the General Safety
Summary and Service Safety Summary found at the beginning of this manual.
Always disconnect the power cord before disassembling any portion of the
oscilloscope.
To prevent damage to electrical components, read Preventing ESD on page 6--1.
H See Figure 10--1 on page 10--7 for an overview of how the entire oscilloscope
is assembled.
H Read the Replacement Procedures on page 6--6 to understand what
procedure to use to access a given module.
H Read Tools Required on page 6--6 for a list of tools needed to remove and
install modules in the oscilloscope.
H If you are disassembling the oscilloscope for cleaning, refer to Inspection
and Cleaning on page 6--2 for cleaning instructions.
The Replaceable Parts section, beginning on page 10--1, lists all of the replace-
able modules.
Disassembly for replacement is best achieved by removing and replacing the
modules in a specified order.
Preparation
List of Modules
Replacement Procedures
