Maintenance
6-- 20
TPS2000 Series Digital Storage Oscilloscopes Service Manual
Troubleshooting
This section contains information and procedures to help you isolate a defective
module in the oscilloscope.
WARNING. Before perform this or any other procedure in this manual, read the
General Safety Summary and Service Safety Summary found at the beginning of
this manual. Also, to prevent possible injury or damage to electrical components,
read Preventing ESD on page 6--1.
If you replace the acquisition circuit board, you must adjust the oscilloscope after
repair. Refer to the chapter Adjustment Procedures on page 5--1.
You may need the the following tools and equipment to troubleshoot the
oscilloscope:
Tools and equipment Example
Oscilloscope with 1X/10X and 100X probes Tektronix TDS1000- or TDS2000-series
oscilloscope with standard accessory 1X/10X
probe (P2200) and optional 100X probe
(P5100 or P5200)
DMM 3.5 or greater digit DMM
To isolate a problem to a specific troubleshooting procedure, use the trouble-
shooting tree in Figures 6--9 through 6--12.
Adjustment After Repair
Required Tools and
Equipment
Troubleshooting Tree
To Next Page
