TEK 1201-N Next Generation Presentation Switcher
www.tekvox.com sales@tekvox.com
the switcher in Auto-Switching and enabling the Output CEC Auto Power modes, allows
the switcher to automatically power on and off a display with CEC control when video is
detected at any of its video input connections. This feature allows the TEK 1201-N to be
used for simple conference rooms and collaboration tables.
4. Front Panel Control
Front panel buttons can be used for switching operations and volume adjusting.
4.1 Manual-Switching
Press 1-HDMI/MHL, 2-HDMI, 3-HDMI, 4-HDMI, 5-HDMI, 6-VGA on front panel to select
the corresponding input source.
4.2 Auto-Switching
Press AUTO to enter in auto-switching mode, and the auto-switching mode abides by
the following principles:
New input
Once detecting a new input signal, the switcher automatically displays this
new signal.
Rebooting device
The switcher has the ability to save the last configuration before losing
power. If rebooted and the last switching mode is auto-switching, the
switcher automatically enters auto-switching mode. If the last displayed
signal is still available, the unit will output this signal. If not, the unit will
detect all the input signals with priority from 1-HDMI to 6-VGA. The first
detected signal is sent to the output.
Signal removing
When signal is removed, the unit will detect all the input signals with
priority from 1-HDMI to 6-VGA. The first detected signal is sent to the
output.
Note: Auto-switching function works only when inputting new signal, removing a signal
or power rebooting. With any VGA port set to C-video or YPbPr, the system will be not
be able to enter in Auto-switching mode.
4.3 Volume Adjusting
Press Volume knob to select MIX or Source audio to adjust, the corresponding LED will
turn green and keep on, and then move the volume knob in clockwise or anti-clockwise
direction to turn up/down sound volume.
