Page #18 background imageLoading...
Page #18 background image
TEK 1201-N Next Generation Presentation Switcher
www.tekvox.com 18 sales@tekvox.com
4.6 RS232 Control
Use the RS232 port on the TEK 1201-N or HDBaseT receiver to control the switcher
using a third party RS232 device. It is also possible to control a display from the switcher
using RS232 at the HDBaseT Receiver. To control the switcher the RS232 commands
must be sent as one packet using a program like Hercules or CommWatch. Do not
terminate with Carriage Return. These same commands are used with TCP/IP port
4001. For feedback the same command is used with terminating <CR><LF>.
Hercules from HW Group http://new.hwg.cz/files/download/sw/version/hercules_3-2-8.exe
HDBaseT Baud rates supported 2400, 4800, 9600(default), 19200, 38400, 57600 or
115200.
RS232 Communication Protocol 4.6.1
Communication protocol: RS232 Communication Protocol
Baud rate: 9600 Data bit: 8 Stop bit: 1 Parity bit: none
Command
Function
Feedback Example
Switch Commands
4.6.2
50701%
Switch to HDMI 1 input
50701<CR><LF>
50702%
Switch to HDMI 2 input
50702<CR><LF>
50703%
Switch to HDMI 3 input
50703<CR><LF>
50704%
Switch to HDMI 4 input
50704<CR><LF>
50705%
Switch to HDMI 6 input
50705<CR><LF>
50706%
Switch to VGA / YPbPr / AV input
50706<CR><LF>
50680%
Set the signal format to VGA for 6-VGA input.
50680<CR><LF>
50681%
Set the signal format to YPbPr for 6-VGA input.
50681<CR><LF>
50682%
Set the signal format to AV(C-video) for 6-VGA
input.
50682<CR><LF>
50785%
Enable auto-switching
50682<CR><LF>
50786%
Disable auto-switching
50786<CR><LF>
Audio Commands
4.6.3
50600%
MUTE Source audio
50600<CR><LF>
50601%
Un-Mute Source audio
50601<CR><LF>
50602%
Source audio volume up
50603%
Source audio volume down
501xx%
Set the Source volume (xx = 00 to 60)
501xx (xx=00~60)
