Tekvox TEK 1201-N User Manual

TEK 1201-N Next Generation Presentation Switcher
www.tekvox.com 41 sales@tekvox.com
5. Specification
Video Input
Video Output
Input
1 HDMI / MHL
4 HDMI
1 VGA
Output
1 HDMI
1 HDBaseT
Input
Connector
5 Female HDMI
1 Female VGA (15 pin)
Output
Connector
1 Female HDMI
1 RJ45
Video Signal
HDMI, YPbPr, C-video,
VGA
Video Signal
1 HDMI
1 HDBaseT
IR Input
IR Output
Input
1 IR IN
Output
1 IR OUT
Input
Connector
3.5mm mini jack
Output
Connector
3.5mm mini jack
Video General
Resolution
Range
1024x768, 1280x720,
1280x800, 1920x1080,
1600x1200,1600x900,
1920x1200
Bandwidth
HDMI:4.95Gbps(1.65Gb
ps per color)
C-Video:150MHz
YPbPr: 170MHz
VGA: 375MHz
Maximum
Pixel Clock
165MHz
Video
Impedance
75Ω
Gain
0dB
Input / Output
Level
0.5V~2.0Vp-p
HDCP
Compliant with DVI & HDMI 1.4 & HDCP 2.2
Audio Input
Audio output
Input
1 3.5mm stereo audio
input for VGA
Output
1 stereo balanced 5 Pin
Phoenix
MIX Input
1 Stereo 3 Pin Phoenix
Line Level
2 3.5mm stereo audio
input for Audio 1&2
Input
Impedance
>10kΩ
Output
Impedance
70Ω
