TEK 1201-N Next Generation Presentation Switcher
www.tekvox.com 32 sales@tekvox.com
Output Adjust: Adjust output image position (X: horizontal direction and Y:
vertical direction), ratio aspect (width and height), polarity adjustment (H
Polarity and V Polarity) and output setting (HDMI on/off and HDBT on/off).
Input 6 Selection: Select video source format for VGA input, includes AV 1
(C-video signal), VGA 1 (VGA signal) and YPbPr 1 (Component video signal).
Baud rate: Set the baud rate for Local and HDBaseT RS232 control: 2400,
4800, 9600, 19200, 38400, 57600,and 115200.
User EDID Load (USB): Insert the USB flash disk with EDID file to
FIRMWARE port to load EDID data through this menu.
RESOLUTION: Set the output resolutions: 1920x1200, 1920x1080,
1600x1200, 1600x900, 1360x768, 1280x800, 1280x720, and 1024x768.
Audio Mute Setup: Turn on/off the Mix, 1-AUDIO, 2-AUDIO, HDMI 1, HDMI 2,
HDMI 3, HDMI 4, HDMI 5, VGA audio.
IP: Shows the current IP address.
Software Update (USB): Insert the USB flash disk with updating file to USB
port of the Scaler Switcher, to update the software through this menu.
Instructions of VGA Converting Cable 4.7.2
VGA inputs support YPbPr and C-video sources. The TEK 1201-N comes with 1 VGA
converting cables to comply with these signals.
When you need to select these signals as an input source, switch to channel INPUT 5
and set the signal type in OSD.
Connect with Component Video (YPbPr) Source
A. Operation Examples:
1. Via front panel buttons & OSD
Press the MENU button on the front panel to enter into OSD. In the OPTION
setting menu, set “INPUT 5 Select” to YPbPr
Via RS232 commands
Send command 50684% to switch to YPbPr source.
2. Via IR remote & OSD
Press the MENU button on the IR remote to enter into OSD and enter into the
OPTION setting menu, set “INPUT 5 Select” to YPbPr source.
