LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 129 of 149 2023-03-16
Not Subject to NDA
Frequency
Band
Freq
[MHz]
LE910C1 -
NA /
LE910C1-
NAD Gain
[dBi]
LE910C1
-NS
Gain
[dBi]
LE910C1/C4
-NF
LE910C1/C4
-NFD
Gain [dBi]
LE910C1
-SV
Gain
[dBi]
LE910C1/C4
-LA
Gain [dBi]
LE910C1
-SA
LE910C1-
SAD
Gain [dBi]
LE910C1
-SAX
LE910C1-
SXD
Gain [dBi]
LE910C1
-ST
Gain
[dBi]
LE910C1/C4
-WWX
LE910C1/C4-
WWXD
Gain [dBi]
600 MHz 600 N/A N/A 5.63 N/A N/A NA NA 5.63 N/A
2600 MHz 2600 N/A N/A N/A N/A 13.0 NA NA NA 9.01
Table 53: Antenna gain from FCC
This transmitter must not be co-located or operating in conjunction with any other
antenna or transmitter.
Frequency
Band
Freq
[MHz]
LE910C1 -
NA /
LE910C1-
NAD Gain
[dBi]
LE910C1
-NS
Gain
[dBi]
LE910C1/C4
-NF
LE910C1/C4
-NFD
Gain [dBi]
LE910C1
-SV
Gain
[dBi]
LE910C1/C4
-LA
Gain [dBi]
LE910C1
-SA
LE910C1-
SAD
Gain [dBi]
LE910C1
-SAX
LE910C1-
SXD
Gain [dBi]
LE910C1
-ST
Gain
[dBi]
LE910C1/C4
-WWX
LE910C1/C4-
WWXD
Gain [dBi]
850 MHz 850 3.64 6.08 6.12 NA 3.5 NA NA NA 3.62
1900 MHz 1900 2.51 8.01 8.01 NA 9.5 8.01 8.00 8.01 8.51
1700 MHz 1700 5.00 5.00 5.00 6.00 13.0 5.00 5.00 5.00 5.50
900 MHz 900 5.00 N/A N/A N/A N/A NA NA NA 7.38
700 MHz 700 5.63 5.63 5.94 6.44 N/A 5.63 5.60 5.63 6.64
600 MHz 600 N/A N/A 5.63 N/A N/A NA NA 5.63 N/A
2600 MHz 2600 N/A N/A N/A N/A 13.0 NA NA NA 9.01
Table 54: Antenna gain from FCC
Labelling requirements for the host device
The host device shall be properly labelled to identify the modules within the host device.
The certification label of the module shall be clearly visible at all times when installed in
the host device, otherwise the host device must be labelled to display the FCC ID of the
module, preceded by the words "Contains transmitter module", or the word "Contains",
or similar wording expressing the same meaning, as in the below table.
Model / HVIN Host device FCC label
LE910C1-NA
LE910C1-NAD*
Contains FCC ID: RI7LE910C1NA
LE910C1-NS Contains FCC ID: RI7LE910C1NS
LE910C1-NF LE910C4-NF
LE910C1-NFD* LE910C4-NFD*
Contains FCC ID: RI7LE910CXNF
LE910C1-SV Contains FCC ID: RI7LE910C1SV
