LE910Cx Hardware Design Guide

1VV0301298 Rev.40 Page 16 of 149 2023-03-16

Not Subject to NDA

Note: The following interfaces are unique to the LE910Cx and may

not be supported on other (former or future) xE910 family. Special

care must be paid when designing the application board if future

compatibility is required:

- SGMII for Ethernet connectivity

- SDIO for WIFI connectivity

- SD/MMC for SD Card connectivity

Warning: LE910C1-EUX, LE910C1-SAX(D), LE910C1-SVX, LE910Cx-

WWX(D) and LE910C1-APX models which are based on ThreadX OS,

does not support the following functions.

 Fastboot

 Wi-Fi / BT

 SD / MMC

 HSIC

 SGMII

 RNDIS over the USB

 NMEA over the USB

 USB Audio

 USB OTG

 Audio playback

 Audio playback during voice call

 Full duplex voice conversation recording (Voice Recording)

 In call music delivery

 AUX PCM interface

 TTY

Block Diagram

Figure 1 shows an overview of the internal architecture of the LE910Cx module.

It includes the following sub-functions:
