10. MOUNTING THE MODULE ON YOUR BOARD
General
The LE910Cx module is designed to be compliant with a standard lead-free soldering
process.
Finishing & Dimensions
The below figure shows the mechanical dimensions of the LE910Cx module.
Figure 25: LE910Cx Mechanical Dimensions (Bottom View) except for LE910Cx-WWX
Lead-free Alloy:
Surface finishing Ni/Au for all solder pads
Pin
B1
