Telit Wireless Solutions LE910C1-AP Hardware Design Guide

LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 37 of 149 2023-03-16
Not Subject to NDA
4. ELECTRICAL SPECIFICATIONS
Absolute Maximum Ratings – Not Operational
Warning: A deviation from the value ranges listed below may harm
the LE910Cx module.
Symbol Parameter Min Max Unit
VBATT Battery supply
voltage on pin
VBATT
-0.5 +6.0 [V]
VBATT TRANSIENT Transient voltage on
pin VBATT (< 10 ms)
-0.5 +7.0 [V]
VBATT_PA Battery supply
voltage on pin
VBATT_PA
-0.3 +6.0 [V]
Table 9: Absolute Maximum Ratings – Not Operational
Recommended Operating Conditions
Symbol Parameter Min Typ Max Unit
T
amb
Ambient temperature -40 +25 +85 [°C]
VBATT Battery supply voltage on pin VBATT 3.4 3.8 4.2 [V]
VBATT_PA Battery supply voltage on pin
VBATT_PA
3.4 3.8 4.2 [V]
I
BATT_PA
+ I
BATT
Peak current to be used to dimension
decoupling capacitors on pin
VBATT_PA
- 80 2000 [mA]
Table 10: Recommended Operating Conditions
