Telit Wireless Solutions LE910C1-AP Hardware Design Guide

LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 25 of 149 2023-03-16
Not Subject to NDA
Mechanical Specifications
2.8.1. Dimensions
The module’s overall dimensions are:
 Length: 28.2 mm, +/- 0.15 mm tolerance
 Width: 28.2 mm, +/- 0.15 mm tolerance
 Thickness: 2.2 mm, +/- 0.15 mm tolerance and
The LE910Cx-WWX module’s overall dimensions are:
 Length: 29.4 mm, +/- 0.15 mm tolerance
 Width: 29.4 mm, +/- 0.15 mm tolerance
 Thickness: 2.2 mm, +/- 0.15 mm tolerance
Note: LE910C1-SV’s thickness is only 2.3mm, +/- 0.15 mm tolerance
Note: Consider a typical label thickness of 0.1 mm in addition to the
module thickness.
2.8.2. Weight
The nominal weight of the LE910Cx module is 5.0 grams.
