LE910Cx Hardware Design Guide
1VV0301298 Rev.40 Page 92 of 149 2023-03-16
Not Subject to NDA
Item Min Max Units
Input voltage range 0.1 1.7 Volt
AD conversion - 8 bits
Resolution - < 6.6 mV
Table 41: ADC Parameters
9.5.2. Using the ADC Converter
An AT command is available to use the ADC function.
The command is AT#ADC=1,2. The read value is expressed in mV.
Refer to Ref 1: LE910Cx AT Command User Guide for the full description of this function.
Using the Temperature Monitor Function
The Temperature Monitor supports temperature monitoring by providing periodic
temperature indications, to perform some functions in extreme conditions. When
properly set (see the #TEMPMON command in Ref 1: LE910Cx AT Command User Guide),
it raises a GPIO to High Logic level when the maximum temperature is reached.
GNSS Characteristics
Table 42 specifies the GNSS characteristics and expected performance. The values are
related to typical environment and conditions.
Parameters
Typical
Measurement
Notes
Sensitivity
Standalone or MS Based Tracking
Sensitivity
-160.0 dBm
Acquisition -147.0 dBm
Cold Start Sensitivity -145.0 dBm
TTFF
Hot 1.1s GPS+GLONASS Simulator test
Warm 22.1s GPS+GLONASS Simulator test
Cold 29.94s GPS+GLONASS Simulator test
Accuracy < 2.0 m
GPS+GLONASS Simulator test @
CEP50
Min Navigation update rate 1Hz
Dynamics 2g
Operation limits 515 m/sec
A-GPS Supported
