Tenda A301 User Manual

1
1 Get to know your device
1.1 Overview
Tenda A301 is a high-performance WiFi extender operating in the 2.4 GHz band. It helps provide a
larger WiFi coverage. Meanwhile, it can work well with mainstream WiFi routers available on the
market.
1.2 LED indicator, button, and label
1.2.1 LED indicators
LED indicator
Status
Description
Signal
Solid blue
The extender has connected to your WiFi router, and its position is
proper.
Solid red
The extender is too far away from your WiFi router.
Relocate the extender closer to the router.
Off
The extender does not connect to your WiFi router.
Signal
WPS
PWR

Tenda A301 Specifications

General

Type	Network transmitter
Maximum transfer distance	- m
Antennas quantity	2
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100Base-T(X)
Security algorithms	WEP, WPA-PSK, WPA2-PSK
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Wi-Fi data rate (max)	300 Mbit/s
RJ-45 ports quantity (transmitter)	1
Output current	0.7 A
Output voltage	5 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	-40 - 70 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE, FCC
Sustainability certificates	RoHS
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	110 mm
Width	55 mm
Height	39 mm
