Tenda AC19 User Manual

104
Configure IPv6 tunnel
⚫
Devices at both ends of the tunnel must support the dual stack protocol.
⚫
The WAN IPv4 address of the routers must be a public IP address.
6in4 tunnel
Log in to the web UI of the router, and navigate to IPv6. Set the connection type to 6in4 Tunnel,
enter required parameters and save the configurations.
Parameter description
Parameter
Description
Remote IPv4 Address
It specifies the WAN IPv4 address of the dual stack router at the peer side.
Local IPv6 Address
It specifies the IPv6 address of the LAN, which needs to be customized.
6to4 tunnel
Log in to the web UI of the router, and navigate to IPv6. Set the connection type to 6to4 Tunnel
and save the configurations.
6rd tunnel
Log in to the web UI of the router, and navigate to IPv6. Set the connection type to 6rd Tunnel,
enter required parameters and save the configurations.

Tenda AC19 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Security algorithms	WPA-PSK, WPA2, WPS
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Antenna gain level (max)	6 dBi
Certification	CE, FCC, RoHS
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	238.9 mm
Width	144.3 mm
Height	403 mm
