8
2.3 Web UI layout
The web UI of the router consists of two sections, including the navigation bar and the
configuration area. See the following figure.
SN
Name
Description
Navigation
bar
It is used to display the function menu of the router. Users can select
functions in the navigation bar and the configuration page appears in the
configuration area.
Configuration
area
It is used to modify or view your configurations.
2
1
