Tenda AC19 User Manual

124
11.3 Tenda WiFi App
The router supports management through the Tenda WiFi App. With the App, you can:
− Manage your router within the LAN or through the internet.
− View and download resources on the USB storage device within the LAN and through
the internet (only available on AC19).
To manage the router with Tenda WiFi App, follow the steps below (Example: iPhone).
Configuring procedure:
Step 1 Go to the App store and search for the Tenda WiFi App. Download and install it on your
phone.
If you already have a Tenda WiFi App account or want to use the fast login approach, skip to Step 3 and
proceed with the settings.
Step 2 (Optional) Register an account in the Tenda WiFi App.
1. Open the Tenda WiFi App, tap the at the top left corner and tap Login.

Tenda AC19 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Security algorithms	WPA-PSK, WPA2, WPS
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Antenna gain level (max)	6 dBi
Certification	CE, FCC, RoHS
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	238.9 mm
Width	144.3 mm
Height	403 mm
