Tenda AC19 User Manual

71
7.2 Configure the parental control rule
Click or +New to edit or add a parental control rule. +New is used for illustration here.
Parameter
Description
Device Name
It specifies the name of the device that the parental control rule applies to.
MAC Address
It specifies the MAC address of the device that the parental control rule applies to.
Internet Accessible At
It specifies the period during which the device can access the internet.
In
It specifies the days when the rule takes effect.
Website Access Limit
It is used to enable or disable the website access limit function.
Access Control Mode
When the website access limit function is enabled, there are two access control
modes available.
⚫
Blacklist: The device is blocked from accessing the websites specified in the rule
during the specified period, but can access other websites. The device cannot
access the internet out of the specified period.
⚫
Whitelist: The device is allowed to access the websites specified in the rule
during the specified period, but cannot access other websites. The device cannot
access any website out of the specified period.

Tenda AC19 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
Security algorithms	WPA-PSK, WPA2, WPS
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, System, USB, WPS
Antenna gain level (max)	6 dBi
Certification	CE, FCC, RoHS
Output current	2 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	238.9 mm
Width	144.3 mm
Height	403 mm
