Tenda F300 User Manual

Wireless N300 Home Router
42
3.8 DHCP
The Dynamic Host Configuration Protocol (DHCP) is an automatic
configuration protocol used on IP networks. If you enable the
built-in DHCP server on the device, it will automatically configure
the TCP/IP settings for all your LAN computers (including IP
address, subnet mask, gateway and DNS etc), eliminating the
need of manual intervention. Just be sure to set all computers on
your LAN to be DHCP clients by selecting "Obtain an IP
Address Automatically" respectively on each such PC. When
turned on, these PCs will automatically load IP information from
the DHCP server. (This feature is enabled by default. Do NOT
disable it unless necessary)

Tenda F300 Specifications

General

Frequency	2.4GHz
Data Rate	300Mbps
Ports	1x 10/100Mbps WAN port, 3x 10/100Mbps LAN ports
Wireless Standards	IEEE 802.11n
Security	WPA/WPA2
Button	Reset button
Antenna	2x 5dBi fixed antennas
Weight	200g
