Tenda F300 User Manual

Wireless N300 Home Router
76
6.2 DMZ Host
The DMZ (De-Militarized Zone) function disables the firewall on the
router for one device for a special purpose service such as Internet
gaming or video conferencing. Enabling DMZ host may expose your
local network to potential attacks. So it is advisable to use it with
caution.
1. DMZ Host IP Address: The IP Address of the device for which
the router’s firewall will be disabled. Be sure to statically set the
IP Address of that device for this function to be consistent.
2. Enable: Check/uncheck to enable/disable the DMZ host feature.
3. OK: Click to enable your settings.
Note: Once enabled, the DMZ host loses protection from device's
firewall and becomes vulnerable to attacks.

Tenda F300 Specifications

General

Frequency	2.4GHz
Data Rate	300Mbps
Ports	1x 10/100Mbps WAN port, 3x 10/100Mbps LAN ports
Wireless Standards	IEEE 802.11n
Security	WPA/WPA2
Button	Reset button
Antenna	2x 5dBi fixed antennas
Weight	200g
