ON TIRES
On tires operation, particularly pick and carry, must be done in a slow, smooth
manner over level terrain that will support the crane, with the loads close to the
ground and the boom as low as possible to avoid the load swinging
unintentionally, causing injury or tip over. Do not pick and carry with the jib since
the load is further extended from the machine and the jib can be easily damaged
The maximum boom length shown on the On Tire chart is the maximum boom length that
can be used at the radius shown. This is done to limit the boom height when working on
tires. Do not exceed the maximum boom length for the given radius.
RT500
Operating Instructions
126 REVISED:
