18. TRANSMISSION TEMPERATURE 28. ENGINE STOP / FAULT
19. TURN SIGNAL INDICATOR 29. IGNITION SWITCH
20. TRANSMISSION OIL PRESSURE 30. LEFT FRONT OUTRIGGER SWITCH
21. LOW AIR PRESSURE 31. RIGHT FRONT OUTRIGGER SWITCH
23. AIR PRESSURE GAUGE 32. LEFT REAR OUTRIGGER SWITCH
24. PARK BRAKE INDICATOR 33. RIGHT REAR OUTRIGGER SWITCH
25. LOW WATER INDICATOR 34. GEAR SELECTOR
26. ENGINE STOP INDICATOR 35. PARKING BRAKE SWITCH
27. ENGINE MAINTENANCE INDICATOR 36. AXLE DISENGAGE/RANGE SHIFT
RT500
Description Of Machine and Controls
46 REVISED:
