37. SWING BEARING GREASE FITTING-
Attach grease gun and swing machine
slowly while applying grease.
50. HEATER ON/OFF SWITCH
38.HAND THROTTLE - Holds engine throttle
at an operator settable position. Place the
accelerator (42) at approximate RPM. Push
in button on hand throttle. Pull throttle up
and release button to lock. Make fine
adjustments to engine RPM by rotating the
hand throttle clockwise to decrease RPM
and counterclockwise to increase RPM.
51. HEATER FAN CONTROL
39. SWING GEAR GREASE FITTING-Attach
grease gun and swing machine slowly while
applying grease.
52. TEMPERATURE CONTROL SWITCH
48. ACCESSORY (10 AMP) PLUG-12 VDC
RT500
Description Of Machine and Controls
56 REVISED:
