Terraplus KT-10 v2 - The KT-10 v2; Specifications

Chapter 2
The KT-10 v2 S/C
2.1 Specifications
Susceptibility Sensitivity: 1x10
-6
SI Units
Conductivity Sensitivity (optional): 1 S/m
Susceptibility Range: 0.001 x 10
-3
to 1999.99 x 10
-3
SI
Conductivity Range (optional): 1 - 100,000 S/m Units Auto-Ranging
Operating frequency: 10 kHz
Measurement Frequency 20 times per second in Scanner
Mode (5 readings are averaged
together and 4 readings per second
are stored)
Display: High Contrast LCD Graphic
Display with 104 x 88 pixels
Memory: Up to 4000 measurements with
voice notes.
Control: One button with up and down
functionality. A PIN mode is
available for rough surfaces.
Communication: USB, Bluetooth and GPS link via
Bluetooth
Battery: Two AA batteries - Rechargeable
or Non-rechargeable
Battery life: Up to 3000 readings without
voice recorder, using alkaline
batteries
Operating temperature: -20 °C to 60 °C
Dimensions: 200mm x 57mm X 30mm
Coil Diameter: 65 mm
Weight: 0.30 kg
9
