3.3 Setup Menu
The Setup menu contains several different parameters to configure the KT-10 v2’s
operation. The selections in this menu are: Mode, Core Diameter, Measure Units,
Date/Time, Accessories, Advanced, and Main Menu. To navigate to the desired
parameter use the SBP▼ or SBP▲, then when the parameter is highlighted use LBP▼
or LBP▲ to activate it.
Figure 8: Setup Menu
Mode: (Optional for KT-10 v2)
KT-10 v2 can be operated in 3 different configurations: measure Magnetic Susceptibility
and Conductivity simultaneously, measure only Magnetic Susceptibility, or measure
Conductivity only.
For ease of operation, the user can select from 4 modes; Susceptibility, Conductivity,
Susceptibility & Conductivity, or Conductivity & Susceptibility.
Figure 9: Mode menu
19
