TerraTec DMX User Manual

SoundSystem DMX 39
!
AES/EBU to S/PDIF
AES out: 2-------330 ohm------------------- SPDIF in
|
3--- 91 ohm
| |
1---------|-----------------------
-
ground
S/PDIF to AES/EBU
_
+ 5 volt | \
SPDIF out: | +-| O-+
_ | |_/ |
diode ^ +-4,7k-+ _ | _ |
10 u (+) | | | | \ | | \ | 100 n
O-----+-||-+--------+--+--IC--+--+-| O-+-| O-+-120 r-||-+----+-- 2
| | | | | | |_/ |_/ | |
| +-||-+ 100n _ 2,2k | 1 k |
75r ^ diode | | IC | | AES in
| | --- | --- |
--- --- | _ 220r
| | \ 100 n |
+--+---| O---+--120 r-||-+---+--- 3
Diode = 1N914 or 1N4148 | |_/ | |
| _ | 1 k +--- 1
| | \ | | |
IC = 74HC04 or CMOS 4049 +---| O---+ --- ---
|_/
Please note. We do not guarantee in any way the safety or the
functioning of this circuit. We also cannot give any technical support
for its implementation.

TerraTec DMX Specifications

General

Interface	PCI
Sample Rate	48 kHz
Channels	6
Digital Audio	Yes
Bit Rate	16 bit
Supported OS	Windows 98/ME/2000/XP
