User's Manual
MH3D
13. Z MOUSE - Used with the control box for menu selection, measurement
point taking, scanning and for data input.
14. AIR SUPPLY - Provides and distributes air to the air bearings for
smooth, frictionless travel of the bridge, carriage and Z rail. The air
supply is also used for the adjustable Z rail counterbalance.
15. AIR BEARINGS - The air bearings provide noncontact, frictionless
movement of the bridge, carriage, and Z rail along their respective ways.
16. MEASURING SYSTEM - A highly accurate, opto-electric system, con-
sisting of a scale and an encoder head, which sends electronic signals to
the readout as it moves along the scale.
17. MACHINE LEVELING FEET - Three screws and pads used to isolate
the machine from vibrations and to level the machine.
18. ANTI-TIP BOLTS - Two bolts in the machine base that prevent the
machine from tipping if it is bumped or has an unbalanced load.
19. GRANITE LEVELING FEET - Three ball-end screws in the top of the
base that provide a three point support for the table. They are also used
to level the granite to the X and Y axes.
20. FINE ADJUSTMENT - Allows precise adjustment of all three axes by
means of knurled knobs .(Optional)
Description
