HYDRAULIC PULLER-TENSIONER PT1250
Manual: MI-PT1250-050-01-IT Date: 06.11.2017 Author: AT Page: 19 of 69
The radio control display is equipped with 4 control pages of the main parameters of the machine, and the
operator cannot remain in the vicinity of the machine control panel.
Led 1: ROPE CLAMP 1 CLOSED
Led 2: NEGATIVE BRAKE BULL-WHEEL 1 OPEN
Led 3: NEGATIVE BRAKE REEL ELEVATOR 1 OPEN
Led 4: OPERATING MODE PULLER TENSIONER, REVERSE FROM THAT SET
Led 5: ROPE CLAMP 2 OPEN (IF PRESENT)
Led 6: NO ATTIVE
Led 7: NO ATTIVE
Led 8: NO ATTIVE
Led 9: NO ATTIVE
Led 10: OIL TOO HOT
Led 11: BULL-WHEEL SELECTION+REEL ELEVATOR DISABLED
Led 12: NO ATTIVE
Led 13: NO ATTIVE
Led 14: NO ATTIVE
Led 15: NO ATTIVE
Led 16: NO ATTIVE
Led indication
Battey
Push button menù
pages.
Working parameter
Alarm Machine
Battery status
Radio status
connection
Led indication machine
To Next Page
