5.5 MULTIFUNCTION DISPLAY AND MACHINE PARAMETERS
The remote control is equipped with a 7 " multifunction display which contains all the commands and
options available machine.
These are enclosed in three main menus, identified by the symbols shown at the bottom right and where
you can find several sub-menus that expand the scope and control of the machine and its functions.
Machine
functions
Available
machine
menu
Machine
alarms
Working
parameters
To access the
menu simply push
the corresponding
button
