Tesmec PT1250 - Hydraulic System Area

HYDRAULIC PULLER-TENSIONER PT1250
Table: MI-TN1250-050-00-IT Data: 13.09.2017 Author: AT Page 5 of 9
Table 5 – Hydraulic System Area
1. Hydraulic Engine – Negative Brake – Main Circuit Gearbox;
2. Hydraulic Oil Filter;
3. Gasoil Filling Plug;
4. Metal Sheet for Diesel Tank Cleaning;
5. Hydraulic Oil Filling Plug;
6. Hydraulic Oil Level;
7. Hydraulic Oil Drain Faucet;
1
7
6
5
3
4
2
